Трактор Малый Вали
 |
 |
 |
|
Технические параметры
| Модель | Размер (д*ш*в) mm |
Мощность двигателя (кв) | Скорость выходного вала(об/мин) |
Перед -колеса (mm) |
Назад -колеса (mm) |
Максим. тяга(KN) | Максим. подъемная сила(KN) |
| M250-E | 3210*1475 *1860 |
18.8 | 540/720 (540/1000) |
1000/1200 /1300 (1050/1150/ 1250) |
960/1460 | 7.8 | ≧4.2 |
| M254-E | 3225*1440 *1900 |
18.8 | 540/720 (540/1000) |
1225/1160 /1040 |
960/1460 | 9.4 | ≧4.2 |
| M300-E | 3340*1500 *2051 |
22.1 | 540/720 (540/1000) |
1000/1200 /1300 (1050/1150/ 1250) |
960/1460 | 9.4 | ≧4.96 |
| M304-E | 3312*1524 *2255 |
22.1 | 540/720(540/ 1000) |
1225/1160 /1040 |
960/1460 | 10.8 | ≧4.96 |
| M320-E | 3340*1500 *2051 |
23.5 | 540/720 (540/1000) |
1000/1200 /1300 (1050/1150/ 1250) |
960/1460 | 10.8 | ≧5.29 |
| M324-E | 3312*1524 *2255 |
23.5 | 540/720 (540/1000) |
1225 | 960/1460 | 13.5 | ≧5.29 |
| M350-E | 3750*1600 *2120 |
25.7 | 540/760 | 1300 (1300-1500) |
1200-1500 | 7.8 | ≧5.8 |
| M354-E | 3480*1500 *2050 |
25.7 | 540/760 | 1330/1210 | 1200-1500 | 9.7 | ≧5.8 |
| M354L-E | 2995*1220 *1200 |
25.7 | 540/720 | 1015 | 1000 | 5.4 | 5.9 |
| M354-H | 3745*1625 *2170 |
25.7 | 540/760 | 1330/1210 | 1200-1500 | 9.7 | ≧5.8 |
| M384-E | 3380*1524 *2050 |
27.9 | 540/720 (540/1000) |
1243 | 1037-1537 | 8.5 | 7.2 |
| M400-B | 3780/3980 *1650*2130 |
29.4 | 540(760), 1000 | 1200-1500 | 1200-1500 | 8 | ≧7.4 |
| M400L-E | 2927*1220 *1200 |
29.4 | 540/760 | 977 | 1200-1500 | 5.3 | 5.9 |
| M400-H | 3886*1600 *2130 |
29.4 | 540/1000 (760/100) |
1300 (1300-1500) |
1200-1500 | 8.5 | ≧6.61 |
| M404-B | 3780/3980 *1650*2130 |
29.4 | 540(760)、 1000 | 1250 | 1200-1500 | 12 | ≧7.4 |
| M450-B | 3980*1650 *2130 |
33.1 | 540(760),、1000 | 1200-1500 | 1200-1500 | 8.5 | ≧8.3 |
| M454-B | 3980*1650 *2130 |
33.1 | 540(760)、1000 | 1250 | 1200-1500 | 13 | ≧8.3 |
| M484-H | 3886*1750 *2150 |
35.1 | 540/1000 (760/100) |
1330 | 1300 | 9.7 | 8 |
| M504-B | 3980*1650 *2130 |
36.8 | 540(760)、1000 | 1250 | 1200-1500 | 14 | ≧9.1 |
| M550-B | 3980*1650 *2150 |
40.4 | 540(760)、1000 | 1200-1500 | 1250-1550 | 9.5 | ≧9.5 |
| M554-B | 3980*1650 *2150 |
40.4 | 540(760)、1000 | 1250 | 1250-1550 | 14.5 | ≧9.5 |
| M600-B | 3980*1650 *2180 |
44.1 | 540(760)、1000 | 1200-1500 | 1250-1550 | 13.5 | ≧11.5 |
| M604-B | 3980*1650 *2150 |
44 | 540(760)、1000 | 1250 | 1250-1550 | 15 | ≧11.5 |
| M704-B | 3980*1650 *2150 |
51.5 | 540/760 (540/1000) |
1450 | 1312/1376 (1408/ 1496) |
13 | ≧15 |
| M750 /754-A |
4200/4285 *1910*2760 |
55 | 540/760 | 1500/1450 | 1530 | 21.7/24 | ≧15 |
| M754-D | 4350*2050 *2810 |
55 | 760/1000 (540/100) |
1610/1710 | ≧15 | ||
| M804-D | 4530*2050 *2810 |
59 | 760/1000 | 1610/1710 | 1680-1996 | 18.6 | ≧15 |
| M820-A | 4285*1910 *2760 |
60.3 | 540/760 | 1500 | 1530 | 24 | ≧15 |
